Open Access

Management of un-ruptured pregnancy in a rudimentary horn of unicornuate uterus at 14 weeks gestation

Gynecological SurgeryEndoscopic Imaging and Allied Techniques20074:279

https://doi.org/10.1007/s10397-007-0279-4

Received: 4 November 2006

Accepted: 13 February 2007

Published: 20 March 2007

Abstract

We present a case of missed miscarriage in an unsuspected non communicating rudimentary horn on a unicornuate uterus. The difficulties of the diagnosis and management of such congenital malformation are described.

Keywords

Rudimentary uterine hornMiscarriageLaparoscopy

Case study

A 23-year-old primigravida at 14 weeks pregnant attended the early pregnancy unit with blood spotting per vagina. She had no significant past medical and surgical history. She appeared well and was haemodynamically stable. The ultrasound scan confirmed a missed miscarriage corresponding to 12 weeks pregnancy with no cardiac activity in an apparent bicornuate uterus. There was no adnexal mass or free fluid. The vaginal examination did not reveal any abnormality and her cervix was normal.

She opted for medical method of evacuation of non viable pregnancy. She had 3 cycles of misoprostol but without success with no further per vaginal bleeding. The surgical method of evacuation was considered under ultrasound guidance and on suction evacuation no products of conception obtained. The tip of the suction canula could not reach the fetal pole. The possibility of a rudimentary horn was then considered and on the subsequent day she consented for a diagnostic laparoscopy and query proceeds of laparotomy for excision of rudimentary horn. She continued to be asymptomatic. The laparoscopy revealed a unicornuate uterus with normal right side horn (Fig. 1a,b). To the left side of the uterus a rudimentary horn was present with an intact round ligament and fallopian tube. This left part of the uterus held the pregnancy, was dilated, inflamed and without signs of rupture (Fig. 2). Both the ovaries were normal and diffuse mild pelvic endometriosis was noted. Laparotomy was done through a Pfannenstiel incision and the rudimentary horn excised. It was found to be non-communicating. The cut section of the specimen contained an intact dead foetus of appreciatively 12 weeks (see photo Fig. 3). The patient recovered without complication in 3 days. Further consultation about fertility issues and exclusion of urinary tractus abnormalities was organised.
Fig. 1

a Laparoscopic view of the rudimentary horn with pregnancy (arrow). b Schematic representation of the non communicating uterine horn (arrow)

Fig. 2

Excision of the rudimentary horn

Fig. 3

Cut section of specimen

Discussion

Background

Unicornuate uterus with pregnancy in a rudimentary horn is an extremely rare clinical scenario that often surprises the gynaecologist or obstetrician. A rudimentary horn is a rare type of congenital uterine anomaly and occurs due to non-coordinated development of one of the mullerian ducts which arrests and fails to fuse with its equivalent on the other side during embryogenesis. The exact incidence of unicornuate uterus is unknown and is difficult to determine since many women with such anomalies are not diagnosed, especially if they are asymptomatic or non pregnant. If an additional rudimentary horn exists, a fibrous or fibro-muscular band usually connects both horns of the ducts but in 80–90% of cases there is no communication between them [1]. The endometrial cavity in the horn can be functional or non functional.

If the rudimentary horn has a functional endometrium and there is no communication with the main uterine horn or uterine body, haematometra and spasmodic dysmenorrhoea may result. This may be the only clinical sign detected [2, 3]. Associated endometriosis is frequent reported [4]. Non communicating uterine rudimentary horn is associated with decreased evacuation of menstrual bleeding per vagina accentuating retrograde menstruation into the peritoneal cavity and therefore possibly increasing the risk of pelvic endometriosis. However, in cases of mullerian uterine malformations, existence of pelvic endometriosis can not clearly be associated with increased risk of missed miscarriage.

The incidence of unicornuate uterus with a rudimentary horn is estimated between 1/100,000 to 1/140,000 [1]. Conception occurs either from the main uterine cavity or from trans-peritoneal migration of the spermatozoa from the controlateral fallopian tube or the fertilised ovum from the ipsi-lateral or controlateral fallopian tube. These pregnancies are characterised by high risk of miscarriage. When the pregnancy exceeds the first trimester there is increased risk of uterine rupture. Over 89% of such pregnancies end-up experiencing rupture in the 2nd trimester and only 1% may succeed with live birth [5]. Uterine rupture in such cases is a serious life threatening situation complicated with maternal haemorrhagic shock [6].

Diagnosis

Diagnosis of pregnancy in a rudimentary horn can be made by ultrasound scan [7]. Sometimes it is not easy to distinguish between a bicornuate “shape” uterus and an uterus that has a rudimentary horn as in our case. Diagnostic hysteroscopy is one of the best tools for assessing the uterine cavity and needs to be considered in cases of uterine malformations. In addition, hysteroscopy could help the diagnosis of a missed miscarriage in a non communicating horn, confirming the absence of pregnancy in the main uterine cavity. MRI is the most useful complementary investigation in order to distinguish between different uterine structural malformations [79]. 3D-ultrasound scan can contribute to the diagnosis when available [10]. However, the definitive diagnosis is made by laparoscopy or laparotomy especially in a case of complication with uterine rupture [6].

Management

In case of a missed miscarriage, a medical approach (mifepristone and misoprostol) has the potential of precipitating uterine rupture in a non communicating horn [11] or failure and must be avoided if there is suspicion of structural uterine malformation. Use of methotrexate was proposed as an alternative solution in early gestational (<7 weeks) pregnancies [12]. The surgical approach should be organised with the appropriate consent prior to any surgical treatment. Clear explanation and description of the malformation is essential for the patient to understand the theurapeutical approach and risks. Issues such as conservative versus radical treatment, surgical risks and difficulties, and risks of ectopic pregnancy must be discussed prior to any intervention. This is especially relevant in clinical situations where there is no emergency. The surgical approach should be preferable via laparoscopy under experienced hands [2].The laparoscopic approach offers decreased hospital stay and postoperative morbidity [13]. However this approach depends on the availability and experience of the surgeon. Referral to a centre of excellence is advised in asymptomatic patients with delayed miscarriage. Conservative surgical options should be offered especially in nulliparous women. Case reports referred further pregnancies after myotomy and exceresis of the rudimentary horn although prematurity is a significant complication in these pregnancies [14, 15]. The kidneys should be evaluated by ultrasound or intravenous pyelograpfhy because of the high incidence of associated renal abnormalities of about 40% [16]. The patient needs to be aware of the potential risk of ectopic pregnancy and to be followed as soon as possible in the early assessment unit. If no pregnancy is wanted, contraception advice should be given.

Conclusion

Delayed miscarriage on congenital uterine malformations in a non communicated rudimentary horn is a rare event and should be managed with caution. Preoperative imaging techniques including ultrasound and MRI are necessary for the assessment of the anatomical malformation. The laparoscopic approach should be considered at first instance. An effort of conservative treatment and less traumatic surgery should be undertaken in cases of nulliparous or infertile women.

Authors’ Affiliations

(1)
Department of Obstetrics & Gynaecology, Royal Preston Hospital

References

  1. Goel P, Aggarwal A, Devi K, Takkar N, Saha PK, Huria A (2005) Unicornuate uterus with non-communicating rudimentary horn—different clinical presentations. J Obstet Gynecol India 55(2):155–158Google Scholar
  2. Theodoridis TD, Saravelos H, Chatzigeorgiou KN, Zepiridis L, Grimbizis GF, Vavilis D, Loufopoulos A, Bontis JN (2006) Anatomical variation in the rudimentary horns of a unicornuate uterus: implications for laparoscopic surgery. Reprod Biomed Online 12(1):128–130PubMedView ArticleGoogle Scholar
  3. Von Eye Corleta H, Villodre LC, Reis R, Capp E (2001) Conservative treatment for a non-communicating rudimentary uterine horn. Acta Obstetricia Et Gynecologica Scandinavica 80(7):668View ArticleGoogle Scholar
  4. Falcone T, Gidwani G, Paraiso M, Beverly C, Goldberg J (1997) Anatomical variation in the rudimentary horns of a unicornuate uterus: implications for laparoscopic surgery. Hum Reprod 12(2):263–265PubMedView ArticleGoogle Scholar
  5. O’Leary JL, O’Leary OA (1963) Rudimentary horn pregnancy. Obstet Gynecol 22:371PubMedGoogle Scholar
  6. Panayotidis C, Abdel-Fattah M, Leggot M (2004) Rupture of rudimentary uterine horn of a unicornuate uterus at 15 weeks gestation. J Obstet Gynaecol 24(3):323–324PubMedView ArticleGoogle Scholar
  7. Tsafrir A, Rojansky N, Sela HY, Gomori JM, Nadjari M (2005) Rudimentary horn pregnancy: first-trimester prerupture sonographic diagnosis and confirmation by magnetic resonance imaging. J Ultrasound Med 24(2):219–223PubMedGoogle Scholar
  8. Pellerito JS, McCarthy SM, Doyle MB et al (1992) Diagnosis of uterine anomalies: relative accuracy of MR imaging, endovaginal sonography and hysterosalpingography. Radiology 183:795PubMedGoogle Scholar
  9. Ozeren S, Caliskan E, Corakci A, Ozkan S, Demirci A (2004) Magnetic resonance imaging and angiography for the prerupture diagnosis of rudimentary uterine horn pregnancy. Acta Radiologica 45(8):878–881PubMedView ArticleGoogle Scholar
  10. Salim R, Woelfer B, Backos M, Regan L, Jurkovic D (2003) Reproducibility of three-dimensional ultrasound diagnosis of congenital uterine anomalies. Ultrasound Obstet Gynecol 21(6):578–582PubMedView ArticleGoogle Scholar
  11. Samuels T-A, Awonuga A (2005) Second-trimester rudimentary uterine horn pregnancy: rupture after labor induction with misoprostol. Obstet Gynecol 106(5 Pt 2):1160–1162PubMedGoogle Scholar
  12. Edelman AB, Jensen JT, Lee DM, Nichols MD (2003) Successful medical abortion of a pregnancy within a non-communicating rudimentary uterine horn. Am J Obstet Gynecol 189(3):886–887PubMedView ArticleGoogle Scholar
  13. Laufer MR (1997) Laparoscopic resection of obstructed hemi-uteri in a series of adolescents. J Pediatr Adolesc Gynecol 10:163Google Scholar
  14. Heinonen PK (1997) Unicornuate uterus and rudimentary horn. Fertil Steril 68(2):224–230PubMedView ArticleGoogle Scholar
  15. Akar ME, Bayar D, Yildiz S, Ozel M, Yilmaz Z (2005) Reproductive outcome of women with unicornuate uterus. Aust N Z J Obstet Gynaecol 45(2):148–150PubMedView ArticleGoogle Scholar
  16. Fedele L, Bianchi S, Agnoli B et al (1996) Urinary tract anomalies associated with unicornuate uterus. J Urol 155:847PubMedView ArticleGoogle Scholar
