Open Access

Mucineus cystadenoma of the appendix presenting as hydrosalpinx—a pitfall in gynaecological medical imaging

  • Lenka Galajdova1Email author,
  • Geert Braems1,
  • Kathleen Lambein2,
  • Wim Ceelen3 and
  • Rudy Van den Broecke1
Gynecological SurgeryEndoscopic Imaging and Allied Techniques20086:387

https://doi.org/10.1007/s10397-008-0387-9

Received: 20 January 2008

Accepted: 11 March 2008

Published: 17 April 2008

Abstract

Mucinous cystadenomas of the appendix represent a very small proportion of the appendiceal pathology, yet, they can lead to a life-threatening condition, such as pseudomyxoma peritonei (PMP), if the diagnosis is delayed. Due to the tubular shape and the proximity of the right adnex, the misdiagnosis of a hydrosalpinx, a condition much more common in women and not requiring an immediate intervention, could be made. We describe a case of a 19-year-old girl presenting with symptoms of acute low abdominal pain. According to the medical imaging (ultrasound and magnetic resonance), a torsion of known chronic hydrosalpinx was suspected and an urgent laparoscopy was performed revealing, surprisingly, an enlarged appendix. Laparoscopic appendectomy was performed without difficulty. The pathology report identified a mucinous cystadenoma. Despite the recent evolution of medical imaging techniques, a misdiagnosis of the nature of a pelvic mass is still possible, leading, occasionally, to the delay of an appropriate treatment. In any case of doubt, a diagnostic laparoscopy should be performed as a golden standard in the diagnosis and management of pelvic adnexal masses in women.

Keywords

Appendix Appendiceal pathology Mucinous cystadenoma Appendiceal tumour Mucinous neoplasm of the appendix Hydrosalpinx Pelvic mass Pseudomyxomatosis peritonei Ovarian mass Ovarian cyst Medical imaging Pelvic ultrasound

Introduction

A tubular-shaped structure found during ultrasound gynaecological examination is routinely considered as being a hydrosalpinx, a pathology treated mostly conservatively, except in the case of infertility or chronic pelvic pain. Appendiceal disorders, on the contrary, generally require an immediate intervention. Our case demonstrates a pitfall in medical imaging, including magnetic resonance imaging (MRI), in the differentiation between those two conditions and stresses the importance of diagnostic laparoscopy in doubtful cases to avoid an unacceptable delay in the treatment of potentially life-threatening illnesses.

Case

A 19-year-old white nulligravida using oral contraception was admitted with acute right iliac fossa pain, nausea and vomiting. Clinical examination revealed abdominal tenderness and rebound pain in the right lower abdominal quadrant and around the umbilicus. Vaginal bimanual palpation and mobilisation of the uterus was rather painful. The patient was pale and in the foetus position, and her temperature was normal. Biochemical inflammatory markers (C-reactive protein 0.2 mg/dl, white blood cells [WBC] 5.7 10E3/μl) and human chorionic gonadotropin (hCG) (<5 mU/ml) were negative. Vaginal ultrasonography showed a tubular structure with dimensions 3×7 cm in the Douglas pouch suggestive of a hydrosalpinx (Fig. 1).
Fig. 1

Echography of the tubular structure

This was her fourth similar episode within a year. The symptoms had always subsided after conservative treatment. The patient was followed up in the outpatient clinic for hydrosalpinx with episodes of intermittent pain attacks and she was put on the waiting list for laparoscopic salpingostomy/salpingectomy. This diagnosis was supported by findings of a sausage-shaped tubular structure in the Douglas pouch on MRI (Fig. 2).
Fig. 2

Magnetic resonance imaging (MRI) of the tubular structure

In the view of the severity of the current episode and the suspicion of complete torsion, an emergency laparoscopy was performed. During the procedure, surprisingly, a complete normal internal genital status was found. In the Douglas pouch, a 6.5×1.6-cm large thin-walled appendix with clear mucinous content and signs of torsion was seen (Fig. 3).
Fig. 3

View of the appendix during laparoscopy

An appendectomy was performed and the pathology report confirmed the diagnosis of mucinous cystadenoma of the appendix (Fig. 4).
Fig. 4

Histopathology

The patient was discharged three days later in good general condition and is currently doing well.

Comment

Mucinous cystadenoma of the appendix belongs to the histological category of mucocoele (mucin-filled cystic dilatation) of the vermiform appendix [1] and is being found in 0.2–0.3% of all appendectomy specimens. Although rare, mucinous cystadenoma represents 63–84% of all mucocoeles [2]. These tumours are benign unless they disseminate through the wall of the appendix or rupture. A correlation between the intraperitoneal spread of neoplastic cells from these mucinous tumours and the clinical picture of pseudomyxoma peritonei (PMP) has been found, though clear evidence of a causal relationship is missing. PMP is a unique slowly progressing condition characterised by extensive mucus accumulation within the abdomen and pelvis, gradually filling the peritoneal cavity, resulting in the characteristic “jelly belly” and leading, inevitably, to intestinal obstruction, nutritional compromise and death, unless definitively treated. Cytoreductive surgery and heated intraoperative intraperitoneal chemotherapy increase the survival rates from zero to approximately 80% [3, 4].

PMP is more common in women between the ages of 40 to 60 years, with an incidence about 1 per million per year [5] and is found unexpectedly in 2 of 10,000 laparotomies [6]. Although it has been reported as originating from many intra-abdominal organs, in the majority of cases, an ovarian of appendiceal cystadenoma or cystadenocarcinoma has been implicated as the primary site.

An association between appendiceal mucocoeles and other tumours involving the gastrointestinal tract, ovary, breast and kidney has also been described [5, 6].

In the view of the rarity of this condition, an error in the diagnosis and treatment may easily occur [4].

Tubal damage is a cause of infertility in about 25% of infertile women. An infective process mediated mostly by chlamydia damages the intraluminal architecture and causes the generation of fluid-filled hydrosalpinges by an unknown mechanism [7].

Hydrosalpinges are usually tubular in shape and may have incomplete septations or nodules in its wall—“beads-on-a-string” sign [8]. On the ultrasound, it can also mimic an ovarian cyst [7, 9]. With the increasing use of transvaginal ultrasound scanning by gynaecologists, it is important to be aware of this. Unfortunately, colour Doppler energy (CDE) imaging and the evaluation of CA 125 plasma concentrations do not seem to increase the accuracy of B-mode transvaginal ultrasonography in differentiating hydrosalpinx from other adnexal masses [8, 10, 11].

As our case shows, even the MRI can be misleading in establishing the correct preoperative diagnosis.

The young age of the patient in our case and pain originating around the umbilicus were more typical for an appendiceal pathology.

Without acute deterioration of the condition requiring an urgent intervention, the delay of the correct management could have occurred until rupture of the appendix with dissemination of the mucinous cells in the peritoneal cavity, calling for chemotherapy in an adolescent.

Appendiceal tumours, though uncommon, should be included in the differential diagnosis of pelvic masses and acute lower abdominal pain in women, especially in the absence of inflammatory markers. Despite the recent evolution of imaging techniques, they are not pitfall-free and diagnostic laparoscopy remains the reference standard in the diagnosis and treatment of female pelvic pathology, thus, “in dubio non abstine.”

Additionally, analysing our own hospital data, we found, surprisingly, that, in a university hospital setting, the prevalence of appendiceal tumours could be much higher than expected (Table 1). In 2006, there were 131 appendectomies performed and 221 appendices sent for anatomopathologic analysis (including debulkings for ovarian carcinoma or colon resections). Of those, there were two mucineus cystadenomas (1.52% or 0.90%, respectively) identified, one of them as a part of PMP (0.76% and 0.45%, respectively) and five adenocarcinomas (3.81% and 2.26%, respectively, all of them being metastatic lesions of ovarium, colon or stomach adenocarcinomas). This strongly contrasts with the literature findings reporting appendiceal mucinous tumours in 0.1–0.3% of all appendectomy specimens, leaving us with a prevalence ten times higher.
Table 1

Overview of the cases of mucinous cystadenoma of the appendix in our hospital from the last ten years

Year

Percentage from all appendectomy procedures

Percentage from all appendices analysed

Mucocoele/appendiceal mucinous tumour

Male (M)/female (F)

Age

Appendiceal mucocoele

Appendiceal carcinoma (CA)

PMP

Other pathologies found

Seen by gynaecologist?

Clinical picture

1996

1.25% (80)

0.66% (152)

1/3

F

47

Yes

No

No

Borderline ovarium tumour

Yes

Acute right fossa pain, known ovarian cyst, suspicion of torsion

F

41

No

Yes

Yes

-

Yes

Secondary amenorrhoea, known endometriosis, cystic mass right adnex

M

72

No

No

Yes

-

NA



1997

1.61% (62)

0.88% (114)

1/1

F

25

Yes

No

No

Retroperitoneal pararectal left endometrioma

Paratubal cyst

Yes

Irregular cycle, suspected ovarian cyst

1998

1.26% (79)

143 (0.69%)

1/1

M

82

Yes

No

No

Adeno CA of the caecum, peri-sacral necrosis

NA

Abdopain

1999

0% (97)

0% (152)

0



2000

0.89% (112)

0.64% (157)

1/1

F

42

Yes

No

No

Endometrioma

Yes

Endometriosis, 8-cm multicystic process right adnex, low abdominal pain

2001

0% (89)

0% (138)

0



2002

0% (111)

0% (162)

0



2003

3.33% (90)

1.85% (162)

3/6

M

54

No

No

Yes

Colon CA, debulking

NA

Haematuria, urinary bladder invasion

F

65

Yes

No

No

Ovarian CA 3 years later

No

Accidental finding of high CEA bulging caecum on ileoscopy

M

82

No

Yes

Yes



NA

Abdopain

F

69

Yes

No

No

Rectum CA in 2000, adhesions

No

Repeated bowel (sub)obstruction, accidental finding

M

60

No

Yes

Yes

Mixed adeno CA/carcinoid CA

NA

Ascites

F

73

Yes

No

No

26-cm ovarian cystadenoma

Yes

Ascites, ovarian mass

2004

1.07% (93)

1.97% (152)

1/3

M

57

Yes

No

Yes

Mucinous tumour of uncertain malignant potential

NA

Peritoneal metastasis, jelly belly

M

63

No

No

Yes

CA caecum

NA

Ferriprive anaemia

F

57

No

Yes

Yes

BCA 2 years later

Yes

Abdopain, ovarian cyst, peritoneal metastases on laparoscopy

2005

2.56% (117)

1.55% (193)

3/4

F

25

Yes

No

No

Liver nodule

No

Painless swelling right fossa, weight loss

F

81

Yes

No

No

Colon CA

No

Abdominal cramps, subobstruction

M

45

No

Yes

Yes

Metastases

NA

Abdominal mass, weight loss

F

69

Yes

No

No

Acute appendix abscess

No

Generally unwell and CEA rise in obese women post-hysterectomy in the past

2006

1.52% (131)

0.90% (221)

2/3

F

72

Yes

No

Yes

Adenoma in both tubes also

No

Ascites, umbilical hernia

M

73

No

No

Yes

-

NA

Incidental finding in inguinal hernia correction

M

45

Yes

No

No

Goblet CA ileum, Crohn’s disease

NA

Obstruction in Crohn’s patient

1996–2006

1.22% (1061)

0.74% (1746)

13/22 (59%)

3M/ 10F

25–82 (57.8)

13/22

5/22

11/22

-

4/10 Yes

-

2007: present case

1.92% (52)

0.70% (142)

1

F

19

Yes

No

No

-

Yes

Suspected torsion of known hydrosalpinx

PMP=pseudomyxoma peritonei; CA=carcinoma

Authors’ Affiliations

(1)
Women’s Health Department, University Hospital Ghent
(2)
Pathology Department, University Hospital Ghent
(3)
General Surgery Department, University Hospital Ghent

References

  1. Misdraji J, Yantiss RK, Graeme-Cook FM, Balis UJ, Young RH (2003) Appendiceal mucinous neoplasms: a clinicopathologic analysis of 107 cases. Am J Surg Pathol 27(8):1089–1103PubMedView ArticleGoogle Scholar
  2. Alrefaie W, Katz MH, Easter DW, Yi SE, Weidner N, Savides TJ, Moossa AR, Bouvet M (2004) Simultaneous serous cystadenoma of the pancreas and mucinous cystadenoma of the appendix. JOP 5(2):97–100PubMedGoogle Scholar
  3. Pseudomyxoma Peritonei Specialty Service. Sugarbaker Oncology Associates (Specialty Section for the Treatment of Appendix Cancer) and the Pseudomyxoma Peritonei Syndrome. Available online at: http://www.surgicaloncology.com/pmp.htm
  4. Atlas of Appendix Cancer andPseudomyxoma Peritonei. Available online at: http://www.surgicaloncology.com/attitle.htm
  5. Bocca SM, Perry R, Oehninger S (2005) Pseudomyxoma peritonei: a rare differential diagnosis of hydrosalpinx. Fertil Steril 84(4):1017PubMedView ArticleGoogle Scholar
  6. Cancer of the appendix and pseudomyxoma peritonei. Available online at: http://www.uptodate.com/patients/content/topic.do?topicKey=gicancer/8601
  7. Griffiths AN, Bhal PS, D’Angelo A (2003) An atypical hydrosalpinx: a differential diagnosis of an ovarian cyst. J Obstet Gynaecol 23(4):452–453PubMedView ArticleGoogle Scholar
  8. Guerriero S, Ajossa S, Lai MP, Mais V, Paoletti AM, Melis GB (2000) Transvaginal ultrasonography associated with colour Doppler energy in the diagnosis of hydrosalpinx. Hum Reprod 15(7):1568–1572PubMedView ArticleGoogle Scholar
  9. Shukla R (2004) Isolated torsion of the hydrosalpinx: a rare presentation. Br J Radiol 77(921):784–786PubMedView ArticleGoogle Scholar
  10. Sonographic differentiation of benign versus malignant adnexal masses. Available online at: http://www.uptodate.com/patients/content/topic.do?topicKey=gen_gyne/14319
  11. Ohara N, Narita F, Murao S (2003) Isolated torsion of haematosalpinx associated with tubal endometriosis. J Obstet Gynaecol 23(4):453–454PubMedView ArticleGoogle Scholar
