Aberrant obturator vessels in minimally invasive pelvic lymph node dissection

  • 1Email author,
  • 1,
  • 1,
  • 1 and
  • 1
Gynecological SurgeryEndoscopic Imaging and Allied Techniques201310:812

https://doi.org/10.1007/s10397-013-0812-6

  • Received: 21 April 2013
  • Accepted: 2 September 2013
  • Published:

Abstract

The presence of aberrant obturator vessels, arising from the external iliac circulatory system and their lesion during a surgical intervention in the area, may lead to bleeding, which is difficult to control. For a period of 5 years, 133 endoscopic bilateral pelvic lymph node dissections in patients with cervical cancer were performed, and the present aberrant vessels were registered and filmed. Aberrant obturator vessels were present in 58 cases (43.6 %). Eight obturator arteries and 58 obturator veins, branches of the external iliac vascular system, were visualized. Arterial type of obturator variation was found in one (0.07 %) case, venous type—in 50 (37.5 %), and combined (arterial and venous) type—in seven (5.26 %), out of all patients. Of the observed aberrant obturator arteries, three were found to arise from the inferior epigastric artery, and five from the external iliac artery. Of all available 73 veins, 51 (70 %) drained directly into the external iliac vein and 22 (30 %) in the inferior epigastric vein. The frequency of the aberrant obturator veins was 27.44 % (n = 73), and of the arteries—3 %, related to the investigated pelvic halves (n = 266). The presence of aberrant obturator vessels is a relatively common anatomic variation, important for the clinical practice.

Keywords

  • Aberrant obturator vessels
  • Corona mortis
  • Pelvic lymph node dissection

Background

Vascular anastomoses, between the obturator and the external iliac arterial and venous systems, are observed in surgical interventions in the obturator and inguinal region. The lesion of the variant obturator vessels may lead to bleeding, which significantly deteriorates the view to the operative field and can seriously impede the surgical team in performing the required intervention. Minimally invasive surgical techniques allow clear visualization of the pelvic structures under optic magnification and require manipulation in bloodless environment. Knowing the anatomical variations of these vascular anastomoses, their protection or selective transection are essential for the smooth course of the retroperitoneal pelvic lymph node dissection.

Materials and methods

The present study includes 133 patients diagnosed with cervical cancer, assessed preoperatively with FIGO stage 1b1. Laparoscopically assisted radical hysterectomy and pelvic lymph node dissection was carried out in 52 patients (from January 2007 to May 2008), and robot-assisted radical hysterectomy and pelvic lymph node dissection in the remaining 81 (from May 2008 to December 2011). All robotic and laparoscopic lymphadenectomies were accomplished by one surgical team, using the same operative methods. Upon resection of the round ligaments, the parietal peritoneum was opened laterally from the infundibulopelvic ligament. The proximal border of the pelvic lymph node dissection was the bifurcation of the common iliac artery and vein, and the distal border was the junction of the deep circumflex iliac vein with the external iliac vein. The inferior epigastric artery (IEA) and the inferior epigastric vein (IEV) were visualized. The superficial and the deep lymphatic chains were removed followed by isolation of the obturator nerve.

The clinical data of the patients in the two groups is presented in Table 1. There were no significant differences between the two groups (p > 0.05), except the lower mean age of the patients in the laparoscopic group (p = 0.001).
Table 1

Characteristics of the patients in laparoscopic and robotic group



Laparoscopic group

Robotic group

Age

40.5 ± 9.9

44.0 ± 11.2

BMI

24.02 kg/m2 (±5.03)

24.51 kg/m2 (±6.11)

Average number of extirpated lymph nodes

11.1 ± 5.1(range 3–25)

11.4 ± 7.0 (range 4–36)

Cases with metastatic lymph nodes (pN1) (FIGO IIIB)

6 (11.5 %)

15 (18.5 %)

Histology

47 (90.3 %)—squamous cell carcinoma

72 (88.8 %)—squamous cell carcinoma

5 (9.6 %)—adenocarcinoma

9 (11.1 %)—adenocarcinoma

All surgical interventions were recorded and the available vascular obturator variations were registered in the course of operation. The records were reviewed later, appropriate images were processed and by using a graphical editor, frames of the basic types of obturator vascular variations were selected. Standard statistical methods were used for data description.

Findings

In most of the cases the obturator vascular bundle was located caudally under the obturator nerve, belonging to the internal iliac vascular system. Aberrant obturator vein (AOV) draining into the external iliac vein (EIV) or the IEV was frequently visualized (43.6 %, n = 58). In some cases, the vein anastomosed with the obturator vein, a branch of the internal iliac vein. Aberrant obturator artery (AOA), arising either from the external iliac artery (EIA), or the IEA, running caudally and medially, to enter with the obturator nerve the canal of the same name, were less often seen (6 %, n = 8). To systematize the cases with vascular variation, a classification proposed by Rusu et al. was used to define three major types of aberrant obturator variations—arterial, venous, and combined [1]. An aberrant obturator vessel was present in 58 cases (43.6 %). There were no significant differences between the robotic and the laparoscopic group, regarding the incidence of the arterial (FET p = 0.092) and venous (χ 2, 2.81; p = 0.094) obturator anastomoses.

Aberrant obturator artery

The presence of AOA was registered in 6 % (n = 8) of the cases. In all the cases, the variation was unilateral. In seven of the cases with AOA, AOV was also present. In half of the patients with arterial obturator variation, the artery was located on the right side, and in the remaining four, on the left side. Of the AOAs found, three arose from the IEA (Fig. 1) and five from the EIA (Fig. 2).
Fig. 1
Fig. 1

The proximal part of the inferior epigastric artery (IEA) is skeletonized and the separation of the aberrant obturator artery (AOA) from it is visualized (right side)

Fig. 2
Fig. 2

Aberrant obturator artery (AOA) separates from the external iliac artery (EIA) between the proximal 2/3 s and distal 1/3 and directs medially and caudally to the obturator canal (left side)

Aberrant obturator vein

Aberrant obturator vein was identified significantly more often than AOA—in 43.6 % (n = 58). In 52 % (n = 30) of the cases, the variation was observed on the right side, in 22 % (n = 13) on the left side, and in 26 % (n = 15) in both pelvic halves.

Seventy-three aberrant obturator veins were found in all studied patients (n = 133). In one case, there were two AOV on the right side, one draining into the external iliac vein, and the other in the inferior epigastric vein (Fig. 3). From the available 73 AOV, 51 (70 %) drained directly into EIV (Fig. 4) and 22 (30 %) in the IEV (Fig. 5). The frequency of AOV related to the studied pelvic halves (n = 266) was 27.44 % (n = 73).
Fig. 3
Fig. 3

Two aberrant obturator veins on the right drain in the inferior epigastric vein (IEV) (AOV1) and the external iliac vein EIV (AOV2), respectively (right side)

Fig. 4
Fig. 4

Aberrant obturator vein (AOV) draining in the external iliac vein (EIV) (left side)

Fig. 5
Fig. 5

Aberrant obturator vein (AOV) draining in the inferior epigastric vein (IEV) (right side)

Types of aberrant obturator variations

The frequency of the aberrant obturator vessels, divided into three main types and associated subtypes by a number of cases (n = 133), is presented in Table 2. In two of the cases, venous anastomoses, between aberrant obturator venous vessel, draining into the external iliac system, and a vessel draining into the internal iliac vein, were dissected (Figs. 6 and 7). Combined arterial and venous type is presented in Figs. 8, 9, and 10.
Table 2

Frequency of the basic types of aberrant obturator vessels



N

% of the cases with aberrant obturator vessel (n = 58)

% of all cases (n = 133)

Arterial type

1

1.72

0.07

OA arises from EIA

0

OA arises from IEA

1

1.72

0.07

Venous type

50

86.20

37.50

OV drains in EIV

31

53.44

23.30

OV drains in IEV

11

18.96

8.27

Venous anastomosis between OV and EIV

2

3.44

1.50

Venous anastomosis between OV and IEV

0

OV drains in EIV + OV drains in IEV

1

1.72

0.07

OV drains in EIV + venous anastomosis between OV and EIV

3

5.17

2.25

OV drains in EIV + venous anastomosis between OV and EIV

1

1.72

0.07

OV drains in IEV + venous anastomosis between OV and IEV

1

1.72

0.07

Arterial and venous variation

7

12.06

5.26

OА arises from EIА + OV drains in EIV

3

5.17

2.25

OА arises from EIА + OV drains in IEV

0

OА arises from IEА + OV drains in EIV

2

3.44

1.50

OA arises from IEА + OV drains in EIV

2

3.44

1.50

Total

58

100

43.60

OA obturator artery, OV obturator vein; EIA external iliac artery, EIV external iliac vein, IEA inferior epigastric artery, IEV inferior epigastric vein

Fig. 6
Fig. 6

Venous anastomosis between the obturator (OV) and aberrant obturator veins (AOV), draining in the internal iliac vein and the external iliac vein (EIV), respectively (right side)

Fig. 7
Fig. 7

Venous anastomosis between the obturator vein (OV) and the inferior epigastric vein (IEV) (right side)

Fig. 8
Fig. 8

Aberrant obturator artery arising from the external iliac artery (EIA) and aberrant obturator vein (AOV) draining in the external iliac vein (EIV) (left side)

Fig. 9
Fig. 9

Aberrant obturator artery arising from the inferior epigastric artery (IEA) and aberrant obturator vein (AOV) draining in the external iliac vein (EIV) (right side)

Fig. 10
Fig. 10

Aberrant obturator artery (AOA) and aberrant obturator vein (AOV) originating from the inferior epigastric artery (IEA) run in parallel and drain in the inferior epigastric vein (IEV), respectively (right side)

Discussion

There is a terminological diversity in defining the atypical vessels in the obturator area. Some authors define as obturator any vessel entering the obturator canal, regardless of its origin, irrespective of its drainage [24]. Von Lanz and Wachsmuth term the veins passing through the obturator canal and draining into the external iliac system, “vv. comitantes” [5]. Berberoğlu et al. term accessory obturator artery/vein any anatomical variant of an obturator vessel, arising from the external iliac system [6]. Other authors prefer the term aberrant obturator vessel, used to denote any abnormal deviation [79]. Rusu et al. perceive the accessory as additional to another existing obturator vein, respectively artery [1]. According to them, in the absence of another obturator vessel, the only one available is the obturator artery, respectively vein, regardless of its origin and drainage. The term “aberrant obturator artery, respectively vein”, describes the atypical course of the blood vessel and in this sense, an obturator vessel can be aberrant, whether arising either from the external iliac circulatory system, or entering atypically the obturator canal.

Due to conceptual differences in terminology, “aberrant obturator artery/vein” was used. The term was used to denote any vessel passing through the obturator canal and connected to the external iliac system. The obturator vessels below the obturator nerve were not always completely dissected, and it was impossible to determine whether the vessel was accessory in relation to another obturator vessel. The risk of inducing bleeding when skeletonizing the vessels in this area may impede the therapeutic and diagnostic procedure. Atypical location of the obturator nerve, artery, and vein, in relation to another one in the fossa, was not considered as aberrant obturator vessel.

The anatomical variations of the obturator vessels are an interdisciplinary problem, concerning different areas of medicine. There is a significant amount of research articles considering this topic. Some of them consider only variants of the arterial obturator vessels [1018]. Other studies discuss the presence of venous aberrant obturator vessels as well [1, 3, 4, 6, 8, 9, 1923].

In most of the publications, data is from cadaver dissections [1, 4, 9, 11, 14, 1824]. In vivo results are presented only in three papers [6, 8, 13] and a case report [15]. Two of the studies are endoscopic, in operative treatment of inguinal hernias. Karakurt et al. study AOA angiographically only in the right pelvic half [13]. Berberoglu et al., apart from a group with cadaver dissection, study a group with endoscopic extraperitoneal dissection in patients with inguinal hernia [6].

No publications concerning aberrant obturator vessels in laparoscopic or robotic transperitoneal iliac lymph node dissection are available in the literature. There were no differences between the robotic and the laparoscopic approach regarding the frequency of the obturator vascular variants. This is most likely due to the lack of considerable differences in the basic patient characteristics, as well as to the fact that all interventions were performed by one team using one and the same technique.

In all cited articles, the data is based on the number of pelvic halves. Due to the fact that our study was totally clinical and the pelvic lymph node dissection performed was bilateral in all 133 cases, we processed the data in relation to the total number of patients as well.

In our opinion, determining the frequency of the anatomical variation by the number of patients studied is as important, as determining its type and frequency by pelvic halves. In the course of the study, it was found that the classification of obturator variations, used by Rusu et al., suited our purposes [1]. The approach we adopted to calculate the frequency of the АОА/AOV types hindered the juxtaposition of data. Therefore, we calculated the frequency, not only by the number of cases, but also by the absolute number of aberrant obturator vessels in pelvic halves.

Aberrant obturator artery was found in eight cases (6 %), distributed by four, in both pelvic halves. The frequency of AOA reported is 3 %, related to 266 pelvic halves. The frequency of AOA ranged from 5.5 % [9] to 65 % [1] in the cited literature. According to Berberoglu et al., the AOA frequency is 8 %, which is similar to our observations [6]. Sarikcioglu et al. observe arterial variation more often (10 %) [4]. Other authors register AOA significantly more frequently than us (20–30 %) [8, 23, 2527].

Of the visualized eight АОА, five originated from IEA, and three directly from EIA. The data presented by most of the authors [1, 1012, 17] are in favor of AOA’s origin from IEA. According to others, АОА is most commonly a branch of EIA [24, 26]. Sarikcioglu et al. have not found any case of АОA originating from IEА [4], while according to М. Berberoglu et al., the frequency of АОА from either IEA or EIA is equal [6].

Bergman et al., in a review article, state that the unilateral presence of АОА, branch of EIA, is comparable in frequency to the bilateral variation [10]. We observed АОА unilaterally only. Another conclusion made by the authors, is that the cases with unilateral АОА, branch of IEA, are equally distributed in both pelvic halves. Our observations confirm a similar distribution pattern of АОА in the left and right pelvic halves.

Papers concerning the venous obturator variations are considerably fewer than the arterial studies, a tendency that is in dissonance with the frequency of the arterial and venous variation. Moreover, some authors even accept the existence of AOV as normal rather than an exception. Berberoglu et al. have found AOV in 96 % of the cases they studied [6]. We calculated the total number of AOV (73), related to 233 pelvic halves 27.44 %, in order to compare our results with those of the cited authors. Our results are similar to those of Missankov et al. (26 %), Sarikcioglu et al. (20.37 %), and Lau et al. (27 %) [4, 8, 24]. In 15 (25.8 %) of the 58 cases identified with AOV, the variation was bilateral. Okcu et al. also found bilateral obturator venous variation in 25 % of the cases [23].

In most of the patients, AOV was visualized only unilaterally (43/74, 13 %), as more frequently, AOV was found in the right side (n = 30), and only in 13 in the left. However, Namking et al. observed approximately equally often venous variation in both pelvic halves [22]. In over half of the cases, AOV was found to drain into EIV (n = 51/69.86 %). Rusu et al. reported that in the pelvises they dissected, AOV was found to drain significantly more often in IEV than in EIV [1]. Other papers, describing the location of influx of AOV were not found in the available literature.

In the patients operated (n = 133), a venous type of obturator variation was observed most often—in 37.50 % of the cases, while the arterial type was seen in only one case (0.07 %). The data of Rusu et al. are quite different from ours. Most often, they observed a combined (arterial + venous) type of obturator variation (40 %), and most rarely a venous type (15 %) [1]. This difference is due to the high frequency of aberrant obturator arteries in their study, unlike the ones identified in our study.

Explanation for the presence of variants of obturator arterial and venous vessels could be sought in the embryonic development of the vascular network. Definitive aberrant obturator artery is formed as a result of uneven growth of anastomoses between the external and internal iliac artery, which are connected in between by variations of the regional organogenesis. Two critical periods are distinguished in the morphogenesis of the anastomoses between the iliac arteries: renal and gonadal obstruction [27]. Obturator vessels are formed relatively late to participate in the blood supply of the lower limb. This could explain the diversity of origin and the relatively high frequency of anatomical variations. According to Arey and Fitzgerald, vascular anomalies are due to an unusual selection of channels from the primary capillary plexus [28, 29]. The most appropriate channels widen, while others atrophy and disappear, thus providing the means of branching of the arterial and venous system.

Conclusion

Pelvic lymph node dissection is a basic procedure for staging and treatment of malignant gynecological diseases. The presence of aberrant obturator vessels is a relatively common anatomic variation, important for the clinical practice. Timely proceeding with the complex oncological therapy is made possible by the absence of complications in the course of surgical intervention and fast recovery of the patient. Last, but not least, the modern minimally invasive techniques, with detailed review of the retroperitoneal anatomy in vivo, may serve for educational purposes in the field of pelvic surgery.
