Efficacy of ovarian suspension to round ligament with a resorbable suture to prevent postoperative adhesions in women with ovarian endometrioma: follow-up by transvaginal hydrolaparoscopy
Gynecological Surgery volume 11, pages261–266(2014)
The aim of this study was to assess the effect of ovarian suspension to the round ipsilateral ligament with a resorbable suture, performed during laparoscopic surgery for endometrioma, on postoperative ovarian adhesion formation. The tool used to assess this effect was not conventional laparoscopy but outpatient transvaginal hydrolaparoscopy. Fifty women with single ovarian endometrioma were divided in two groups (group A, 24 and group B, 26). All patients underwent laparoscopic ovarian cystectomy for endometriosis. In group A, the ovary was suspended to the ipsilateral round ligament. In group B, ovarian suspension was not performed. All patients underwent transvaginal outpatient hydrolaparoscopy as follow-up. A significantly lower rate of postsurgical ovarian adhesion in group A in comparison with group B (33.3 vs 80.8 %—p = 0.001) was observed. Operative time and postoperative pain were similar in both groups. Ovarian suspension to the ipsilateral round ligament with a resorbable suture during surgery for endometrioma is associated with a lower rate of postoperative ovarian adhesion formation.
Ovarian endometriomas are a form of ovarian endometriosis, classified as cysts within the ovaries  accounts for 35 % of benign ovarian cysts , and are present in 17–44 % of patients with endometriosis. Expectant management is not an option for women with endometrioma because of severe symptoms .
Operative laparoscopy is the first-line treatment option available to the general consensus in the treatment of endometriomas >3 cm. However, debate still continues on the type of laparoscopic procedure. The main point of debate is excision or ablation of the cyst capsule [3, 4]. Since the ovarian endometrioma is a pseudocyst, excisional surgery involves the removal of ovarian cortex with primordial follicles, reducing the fertility potential of the affected ovary, especially when extensive hemostasis irreversibly diminishes or impairs the blood supply towards the affected ovary. Ovarian cystectomy for endometriomas seems to cause significant damage to ovarian reserve with up to 40 % fall in serum AMH concentration [5, 6]. According to Donnez et al., cystectomy may be destructive for the ovary, whereas ablation may be incomplete with a greater risk of recurrence . With the combined technique (excision of a large part of endometrioma wall with vaporization of the remaining 10–20 % of endometrioma wall close to the hilus), we achieve the benefits of stripping on symptoms and recurrence, and a less harmful effect of ablation on ovarian reserve.
Adhesions formation rate after laparoscopic endometriosis surgery has been reported in more than 80 % cases [8–11]. The most common site of postoperative adhesions formation is between the ovary and the pelvic wall . Notwithstanding the advances in surgical techniques  and the use of surgical anti-adhesive agents, the incidence of adhesion-related complications do not seem to have significantly declined .
The aim of this study was to assess the effect of ovarian suspension to the round ipsilateral ligament with a resorbable suture, during laparoscopic surgery for endometrioma in terms of postoperative ovarian adhesions after surgical procedure evaluated with office transvaginal hydrolaparoscopy.
This study was performed in the Infertility Clinic of our Department. During the period from March 2010 to March 2012, 185 women affected by endometriosis were evaluated for inclusion in the study. Inclusion criteria were: age between 18 and 40 years; history of infertility >2 years; single endometrioma cysts ≥4 or ≤7 cm  on preoperative ultrasound screen. Patients with smaller endometriomas were excluded because treatment of endometriomas of 1–3 cm was recommended only for the treatment of pain. When endometriosis is identified at laparoscopy, it is recommended to surgically treat endometriosis, as this is effective for reducing endometriosis-associated pain . In these cases, we performed drainage and coagulation of the endometrioma wall because of the possible difficulty in the removal of very small cysts, due to the absence of a clear surgical plane.
Exclusion criteria were: masses occupying the Douglas pouch; previous surgery for endometriosis or additional concomitant surgical procedure planned during the laparoscopic procedure; current pregnancy, including ectopic pregnancy; serum glutamic-oxaloacetic transaminase (sgot), serum glutamate pyruvate transaminase (sgpt), and/or bilirubin >20 % above the upper limit of the normal range; azotemia and creatinine >30 % above the upper limit of the normal range; concurrent use of systemic corticosteroids, antineoplastic agents, and/or radiation; and active pelvic or abdominal infection.
The study was approved by the Institutional Review Boards of our Institution and all patients gave informed consent to participate in the study. Eighty-three patients matched the inclusion criteria and agreed with the study protocol, 21 however refused to participate to the study. Sixty-two patients were divided into two groups (group A, n = 31; group B, n = 31). Patients in group A underwent ovarian suspension to round ligament, while patients in group B did not undergo additional procedures other than that indicating laparosocopy. Both patients and surgeons performing THL were blinded with regard to which cases had their ovaries suspended and which cases did not.
The laparoscopic procedure was performed in the modified dorso-lithotomic position under endotracheal general anesthesia. After pneumoperitoneum induction with a Veress needle and introduction of a 10-mm laparoscope (Karl Storz—Tuttlingen, Germany) in the standard umbilical position, three 5-mm trocars were placed in the following positions: suprapubic, left iliac fossa, and right iliac fossa. After careful exploration of the pelvic organs and upper abdomen, patients with single endometrioma adherent to the ipsilateral fossa were included, while patients with clinical evidence of cancer, rectovaginal endometriosis or bilateral endometriosis were excluded.
Light adhesions on the controlateral adnexa and/or small subserousal uterine myomas observed at first surgery were not considered as exclusion criteria. Ovarian endometriomas were removed following the technique described by Donnez . Briefly, the ovarian cyst was opened and its content drained, the cleavage plane was found and the pseudo-capsule was separated from the ovarian parenchyma by means of repeated diverging traction applied with atraumatic forceps. Light coagulation with bipolar forceps was performed only if necessary, exclusively inside the ovarian parenchyma, before closure of the ovary. The suture was performed using a single running suture with an absorbable monofilament suture (Vicryl Rapid 2.0, CT-1 needle, Sommerville, NJ, USA, Ethicon) with intraovarian knots. Ovarian suture was performed so that no coagulated tissue was detectable outside as previously reported . In group A, the ovary was suspended to the ipsilateral round ligament using an absorbable monofilament suture (Vicryl Rapid 2.0, CT-1 needle, Sommerville, NJ, USA, Ethicon). The suture was performed approximately 1 cm from the inguinal canal, to separate the ovary approximately 1.5–2 cm from the ovarian fossa (Fig. 1). In group B, ovarian suspension was not performed.
The operation time was calculated from the induction of pneumoperitoneum to desufflation. Blood loss during surgery was estimated by measuring the aspirated blood volume. Surgery was performed with an indwelling Foley catheter in situ that was removed as soon as the patient could independently reach the toilet. Twenty-four hours after the procedure, postoperative pain was evaluated using a pain visual analogue scale (VAS) ranging from 0 (absence of pain) to 10 (maximum pain). Per protocol, patients were discharged from the hospital 2 days after the procedure if no complication arose during the postoperative period. All patients were evaluated 60–90 days after surgery with transvaginal outpatient hydrolaparoscopy (THL). THL was not performed before because patients may not agree to undergo a second invasive procedure immediately after the initial surgery.
Transvaginal hydrolaparoscopy was performed by three surgeons: M.P. who performs approximately 100 procedures per year; U.C. and P.G. who perform about 25 procedures per year. Fertiloscopy was performed under local anesthesia with the patient in the lithotomic position. A Collin’s speculum was placed in the vagina and a local anesthetic solution containing mepivacaine hydrochloride 3 % was injected in the posterior fornix, 1–2 cm below the cervix and on the posterior lip of the cervix which was grasped. A specially designed needle dilating trocar system with a total diameter of 3.9 mm (reusable system by Karl Storz Endoscopy—Tuttlingen, Germany) was placed 10–20 mm below the insertion of the posterior vaginal wall to the cervix. A 2.7-mm-diameter semi- rigid endoscope was used with an optical angle of 30°. The correct intra-abdominal trocar position was confirmed visually, and a slow continuous infusion of warmed saline solution was started [17, 18]. To keep the bowel and tubo-ovarian structures afloat the illumination was provided by a high-intensity cold-light source via fiber-optic lead. The images were viewed on high-resolution color monitor. The posterior wall of the uterus was inspected. Subsequently, by rotation and deeper insertion of the scope, the tubo-ovarian structures were visualized. Success was defined as the absence of any adhesion between the ovary and the ovarian fossa (Fig. 2). The vaginal fornix was left to close spontaneously, and antibiotic prophylaxis was prescribed.
The primary end-point was the proportion of women without ovarian adhesions as evaluated by THL 60-90 days after the primary surgical procedure. We hypothesized that women underwent ovarian suspension would develop ovarian adhesion in 30 % of cases as opposed to 70 % of women not undergoing this procedure. Considering these proportions, we calculated that we would need a sample size of 24 in group A and 24 in group B to give 90 % power to detect a significant difference between ovarian suspension and non ovarian suspension procedures with a one-sided type 1 error of 5 %. To account for loss to follow-up, we chose to enroll 31 patients in group A and 31 in group B. Secondary end-points were operative times, intra-operative blood loss, and intra- and postoperative complication rate.
Statistical analysis was performed using the Statistical Package for Social Science, version 15.0 (SPSS, Chicago, IL, USA). Data distribution for continuous variables was assessed with the Shapiro–Wilk’s test. Difference in proportions between groups for the primary end-point was analyzed using the χ 2 test and the odds ratios were calculated. Student’s t test for unpaired samples was used to compare parametric variables between groups. The Mann-Whitney test was used to analyze differences in non parametric parameters between groups. Analysis was performed both per protocol and on an intention-to-treat basis. Separate analysis was carried out considering all drop-outs as having formed adhesions (failures) or not having formed adhesions (successes) between the ovary and its fossa. Significance was set for a value of p < 0.05.
Characteristics of patients are listed in Table 1. No statistical differences were observed in any variable between the two groups. In group A, three patients were excluded intraoperatively from the study for the presence of contralateral ovarian adhesions at laparoscopy and one patient for the presence of two ovarian cysts; in group B three patients were excluded for endometriosis stages III–IV (ASRM).
Five patients (three from group A and two from group B) dropped out of the study: one patient was pregnant to follow-up, two patients refused to undergo THL, and in two patients THL was not possible to perform for poor compliance (pain in the positioning of speculum or trocar in the posterior fornix).
Thus, a total of 24 women in group A and 26 women in group B were available for the analysis. In all the 50 procedures, it was possible to enter the pelvic cavity and visualize the pouch of Douglas.
At the THL control, a significant higher proportion of patients for group A were free of adhesions in comparison with patients from group B (Table 2; p = 0.001). Analyses considering all patients as failures (i.e., with adhesions formation between the ovary and its fossa) or success (i.e., non adhesions formation) confirmed that ovarian suspension leads to a significantly higher proportion of patients who did not develop adhesions (Table 2).
We did not observe any difference in terms of postoperative pelvic pain between the two groups, according to VAS scale (4.78 ± 1.48 in group A vs 4.05 ± 1.67 in group B; p < 0.16).
The operating time was similar between group A and group B (p = 0.11). No major complications (rectum perforation) were reported in both groups. At follow-up, no ovary was still suspended to the round ligament; in all patients from group A, the ovary was found in its anatomical location.
Endometriosis is a complex and heterogeneous condition characterized by a continuous state of inflammation that causes symptoms of pelvic pain and infertility. In this condition, fibrosis and adhesions are common. Some authors support that the inflammatory response may be the first cause of adhesion formation . It leads to an upregulation of tissue factors by peritoneal cells and local macrophages. This causes activation of the extrinsic pathway of the coagulation cascade and the formation of an exudate rich in fibrin . Adhesions can lead to infertility, dyspareunia, chronic pelvic pain, and complications at repeated surgery [20, 21]. Adhesions may produce disruption of the normal anatomy, thus altering normal tubal performance. Thus, follicular growth, pick-up of the oocyte after ovulation and spermatozoa or embryo transport may be impaired . Several women develop postoperative adhesions after laparoscopy surgery. The most common site of postoperative adhesions formation is the ovary [12, 22]. Although several surgical measures and systemic pharmacologic treatments for adhesions prevention have been proposed, the rate of periovarian adhesion formation was not significantly reduced [13, 20–22]. The high incidence of postoperative adhesions in endometriosis patients and their clinical significance underline the importance of modifying surgical technique in order to reduce potential adhesion formation.
Adhesions may develop in locations previously unaffected (de novo) or in locations where adhesiolysis was performed (recurrence). The process of adhesions formation begins during surgery; the possible development of adhesions is determined within the first 7 days of the injury. In the injured area, a gel matrix of fibrin will form and macrophages recruit new mesothelial cells over the damaged surface which reaches the reconstruction of the mesothelial lining within 5–7 days. The adhesions will take place if the surfaces damaged remain in contact [23, 24]. This finding supports the idea of an ovariopexy.
Several authors previously proposed ovarian suspension techniques [25–30] (Table 3). The technique most frequently described has been temporary ovarian suspension to anterior abdominal wall [25–28]. This technique showed only limited results, with success rates ranging from 80 to 40 %. Moreover, this technique carries potential risks of infection due to the proximity of the ovary to the external abdominal wall. Only one author reported  an ovarian suspension to the round ligament, showing no dense adhesion of the ovary to the pelvic sidewall after definitive ovarian suspension to the round ligament. These results are in accordance with our findings. The main drawback of previous analysis was the significant loss to follow-up. Indeed, in all previous studies, second-look surgery was performed only in a small number of patients (Table 3), since systematic laparoscopic second-look may be frequently refuted by patients. In this study, we used an office-based procedure performed under local anesthesia that should increase the compliance of patients in undergoing follow-up second-look.
Indeed, only five patients refused to undergoing second-look with THL, supporting this hypothesis. This is to our knowledge, the first study using Vycril Rapid to suspend the ovary to the round ligament. Because development of adhesion is determined within the first 5–7 days after surgery, we prefer to use Vicryl Rapid 2.0 suture for its characteristics loss of tensile strength in 5–7 days and fast reabsorption process. The ovary so remains separated from the peritoneum of the ovarian dimple for about 7 days, the time necessary for adhesions formation. In the present study, no significant difference was observed in terms of operative time.
Moreover, we did not observe a difference in terms of postoperative pain evaluated according to VAS scale. We believe that no difference in postoperative pain between the two groups is linked to the ovarian suspension technique used. We suspend the ovary approximately 1.5 cm from ovarian fossa with tension-free suture.
This study has several advantages. It can rely on effective blinding of the surgeon performing THL, so that a bias in determining adhesion formation is unlikely. Moreover, it was correctly powered to detect significant differences between the two groups. Finally, sensitivity analysis was performed to address differences in losses to follow-up in the two arms. A potential limitation of the study may be the nonrandomized design of the study that may lead to an allocation bias. Nevertheless, the population selected for the study was homogeneous, so that differences in the two groups are unlikely. Another potential limitation is the low external validity due to strict inclusion criteria. These criteria were chosen in order to evaluate the net effect of the proposed technique on adhesion formation rate due to the suturing of the ovary, avoiding interference of other factors.
Prospective comparative studies including more patients should be conducted to confirm our preliminary results.
In conclusion, this study seems to indicate that ovarian suspension to the round ligament with short-term resorbable suture may be a simple and effective surgical technique for the prevention of periovarian adhesion formation and could be included into the routine surgical procedure for single endometrioma. Moreover, THL can be considered to be a simple and minimally invasive technique with a good compliance for the postoperative follow-up, to evaluate adhesion formation.
Benschop L, Farquhar C, van der Poel N, Heineman MJ (2010) Interventions for women with endometrioma prior to assisted reproductive technology. Cochrane Database Syst Rev 10(11):CD008571
Gruppo italiano per lo studio dell’endometriosi (1994) Prevalence and anatomical distribution of endometriosis in women with selected gynaecological conditions: results from a multicentric Italian study. Hum Reprod 9(6):1158–62
Hart R, Hickey M, Maouris P, Buckett W, Garry R (2008) Excisional surgery versus ablative surgery for ovarian endometriomata. Cochrane Database Syst Rev 16(2):CD004992
Patrelli TS, Berretta R, Gizzo S, Pezzuto A, Franchi L, Lukanovic A, Nardelli Bacchi Modena A (2011) CA 125 serum values in surgically treated endometriosis patients and its relationships with anatomic sites of endometriosis and pregnancy rate. Fertil Steril 95:393–396
Raffi F, Metwally M, Amer S (2012) The impact of excision of ovarian endometrioma on ovarian reserve: a systematic review and meta-analysis. J Clin Endocrinol Metab 97(9):3146–3154
Alborzi S, Keramati P, Younesi M, Samsami A (2014) The impact of laparoscopic cystectomy on ovarian reserve in patients with unilateral and bilateral endometriomas. Fertil Steril 101(2):427–434
Donnez J, Lousse JC, Jadoul P, Donnez O, Squifflet J (2010) Laparoscopic management of endometriomas using a combined technique of excisional (cystectomy) and ablative surgery. Fertil Steril 94(1):28–32
diZerega GS (1994) Contemporary adhesion prevention. Fertil Steril 61:219–235
Mais V, Angioli R, Coccia E, Fagotti A, Landi S, Melis GB, Pellicano M, Scambia G, Zupi E, Angioni S, Arena S, Corona R, Fanfani F, Nappi C (2011) Prevention of postoperative abdominal adhesions in gynecological surgery. Consensus paper of an Italian gynecologists’ task force on adhesions. Minerva Ginecol 63(1):47–70
Redwine DB (1991) Conservative laparoscopic excision of endometriosis by sharp dissection: life table analysis of reoperation and persistent or recurrent disease. Fertil Steril 56:628–634
Operative Laparoscopy Study Group (1991) Postoperative adhesion development after operative laparoscopy: evaluation at early second look procedure. Fertil Steril 55(4):700–704
Ahmad G, Duffy JM, Farquhar C, Vail A, Vandekerckhove P, Watson A, Wiseman D (2008) Barrier agents for adhesion prevention after gynaecological surgery. Cochrane Database Syst Rev 16:CD000475
Pellicano M, Bramante S, Guida M, Bifulco G, Di Spiezio Sardo A, Cirillo D, Nappi C (2008) Ovarian endometrioma: postoperative adhesions following bipolar coagulation and suture. Fertil Steril 89(4):796–9
Lower AM, Hawthorn RJ, Clark D, Boyd JH, Finlayson AR, Knight AD, Crowe AM, Surgical and Clinical Research (SCAR) Group (2004) Adhesion-related readmissions following gynaecological laparoscopy or laparotomy in Scotland: an epidemiological study of 24 046 patients. Hum Reprod 19:1877–85
Dunselman GA, Vermeulen N, Becker C, Calhaz-Jorge C, D’Hooghe T, De Bie B, Heikinheimo O, Horne AW, Kiesel L, Nap A, Prentice A, Saridogan E, Soriano D, Nelen W (2014) ESHRE guideline: management of women with endometriosis. Hum Reprod 29(3):400–412
Jacobson TZ, Duffy JM, Barlow D, Koninckx PR, Garry R (2009) Laparoscopic surgery for pelvic pain associated with endometriosis. Cochrane Database Syst Rev 7(4):CD001300
Verhoeven HC, Brosens I (2005) Transvaginal hydrolaparoscopy, its history and present indication. Minim Invasive Ther Allied Technol 14(3):175–180
Pellicano M, Catena U, Di Iorio P, Simonelli V, Sorrentino F, Stella N, Bonifacio M, Cirillo D, Nappi C (2007) Diagnostic and operative fertiloscopy. Minerva Ginecol 59(2):175–181
Imai A, Suzuki N (2010) Topical non-barrier agents for postoperative adhesion prevention in animal models. Eur J Obstet Gynecol Reprod Biol 149:131–135
Davey AK, Maher PJ (2007) Surgical adhesions: a timely update, a great challenge for the future. J Minim Invasive Gynecol 14:15–22
Robertson D, Lefebvre G, Leyland N, Wolfman W, Allaire C, Awadalla A, Best C, Contestabile E, Dunn S, Heywood M, Leroux N, Potestio F, Rittenberg D, Senikas V, Soucy R, Singh S (2010) Adhesion prevention in gynaecological surgery. J Obstet Gynaecol Can 32:598–60
Ahmad G, Duffy JM, Farquhar C, Vail A, Vandekerckhove P, Watson A, Wiseman D (2008) Barrier agents for adhesion prevention after gynaecological surgery. Cochrane Database Syst Rev 16:CD000475
Holmdahl L, Risberg B, Beck DE Burns JW, Chegini N, di Zerega GS, Ellis (1997) Adhesions: pathogenesis and prevention-panel discussion and summary. Eur J Surg Suppl 557:56–62
di Zerega GS, Campeau JD (2001) Peritoneal repair and post-surgical adhesion formation. Hum Reprod Update 7:547–55
Sedbon E, Madelenat P, Asher E, Palmer R (1983) Suspension temporaire des ovaires dans la prévention de la récidive adhérentielle après salpingostomie terminale. Gynecologie 34:421–4
Redwine D (2001) Laparoscopic ovarian suspension. Fertil Steril 76:105
Abuzeid MI, Ashraf M, Shamma FN (2002) Temporary ovarian suspension at laparoscopy for prevention of adhesions. J Am Assoc Gynecol Laparosc 9:98–102
Ouahba J, Madelenat P, Poncelet C (2004) Transient abdominal ovariopexy for adhesion prevention in patients who underwent surgery for severe pelvic endometriosis. Fertil Steril 82:1407–11
Mitwally MF, Palmer KG, Elhammady E, Eddib A, Diamond MP, Abuzeid MI (2006) Ovarian suspension during laparoscopic conservative surgery for endometriosis—associated infertility: a cohort of 59 consecutive cases. J Minim Invasive Gynecol 13:S50
Carbonnel M, Ducarme G, Dessapt AL, Yazbeck C, Hugues J, Madelenat P, Poncelet C (2011) Efficacy of transient abdominal ovariopexy in patients with severe endometriosis. European J Obstet Gynecol Reprod Biol 155:183–187
Conflict of interest
Massimiliano Pellicano, Pierluigi Giampaolino, Giovanni Tommaselli, Ursula Catena, Carmine Nappi and Giuseppe Bifulco declare that they have no conflict of interest.
All procedures followed were in accordance with the ethical standards of the responsible committee on human experimentation (institutional and national) and with the Helsinki Declaration of 1975, as revised in 2000. Informed consent was obtained from all patients for being included in the study.
